T3 - SPARE PARTS LIST v3.0 7/2003
No. Qty. Desc. Ref.
1 1 Stator Housing WP-T3/001
2 1 Top Vent Housing WP-T3/002
3 1 Base Complete WP-T3/003
4 7 Spring Washer 4mm WP-T3/004
5 1 Washer 4mm x 7mm x 0.8mm WP-T3/005
6 1 Cable Guard WP-T3/006
7 1 Speed Control Circuit Board 240V & Capacitor WP-T3E/007
8 - - -
9 1 Resistor WP-T3/009
10 1 Carbon Brush 240V 2 sets WP-T3E/010
11 2 Brush Holder WP-T3/011
12 2 Circlip 5mm WP-T3/012
13 2 Column End Cap WP-T3/013
14 2 Plunge Locking Screw LH WP-T3/014
15 1 Cable Clamp WP-T3/015
16 2 Machine Screw Dome M4 x 12mm Pozi WP-SCW/07
17 1 Switch 240V WP-T3E/017
18 1 Push Rod WP-T3/018
19 1 On / Off Lever WP-T3/019
20 1 Spring 27mm WP-T3/020
21 2 2 Core Cable with Plug 240V UK WP-T3/021
22 1 Field Complete 240V WP-T3E/022
23 1 Baffle WP-T3/023
24 2 Machine Screw Pan M4 x 58mm Pozi WP-T3/024
25 1 Top Bearing 7mm x 22mm x 7mm 627ZZ WP-T3/025
26 1 Armature 240V with Fan WP-T3E/026
27 1 Lower Bearing Housing WP-T3/027
28 1 Lower Bearing 17mm x 35mm x 10mm 6003ZZ WP-T3/028
29 1 Circlip Wp-T3/029
30 1 Collar WP-T3/030
31 1 Seal WP-T3/031
32 1 Bearing Lock Plate WP-T3/032
33 1 Collet Spring WP-T3E/033
34 1 Collet 6.35mm (
1
⁄ 4 ”) CLT/T3/635
1 Collet 6mm CLT/T3/6
1 Collet 8mm CLT/T3/8
35 1 Collet Nut CLT/NUT/T3
36 1 Depth Stop WP-T3/036
37 1 Middle Frame WP-T3/037
38 1 Thumb Knob WP-T3/038
39 1 Spring 8mm WP-T3/039
40 1 Base Housing Lock Nut WP-T3/040
41 1 Set Screw Hex M6 x 45mm WP-T3/041
42 1 Circlip 17mm WP-T3/042
