Specification
Hardware
Standards
Compliant with ADSL standards
- ANSI T1.413 Issue2
- G.992.1 (G.dmt, Annex A)
- G.992.2 (G.lite)
Compliant with ADSL2 standard
- G.992.3 (G.dmt.bis, Annex L)
Compliant with ADSL2+ standard
- G.992.5 Annex A and M
IEEE 802.3u 10/100Base TX Fast Ethernet
Protocol
TCP/IP,NAT, HTTP, DHCP Server/Relay/Client, DDNS, DNS Proxy,
UPNP, RIP (v1 and v2)
Firewall
Network Address Translation (NAT)
Stateful Packet Inspection (SPI)
Packet Filtering – IP, MAC, Domain
Management Access Control for LAN
ATM
VC and LLC Multiplexing
Bridged/Routed Ethernet over ATM (RFC1483/2684)
OAM F4/F5 loop-back
ATM AAL5 adaptation
PPP over ATM (RFC2364)
PPP over Ethernet (RFC2516)
ATM Traffic Shaping QoS(UBR, CBR, rt-VBR, nrt-VBR)
Management
Web based Configuration (HTTP)
Command Line Interface (CLI) via Telnet
SNMP v2c
IGMP v1 and v2
SW upgrade
ATM PVC Remote Management
WAN Port (ADSL line Interface)
1 x RJ-11 port
LAN Port
4 x 10/100Mbps Auto-MDIX RJ-45 port
Reset Button
Reset to factory default
On/Off Power Button
Power on/off button
LED
Power, LAN: Link/ACT, ADSL, Internet
Power
A: 9V, 1A external power adapter
EU : 9V, 0.5A external power adapter
Power Consumption
5 watts
Dimensions
145 x 113 x 27 mm (5.7 x 4.4 x 1.1 in)
Weight
280 g (9.9 oz)
Temperature
Operating: 5° ~ 45° C (41° ~ 113° F),
Storage: -20° ~ 60° C (-4° ~ 140° F)
Humidity
Max. 90% (non-condensation)
Certifications
CE, FCC
