Hardware Feature
Front Panel
• Housing: IP 66/67 housing
Bottom Panel
• LED
o LAN: Turns on when there is a LAN connection and blinks when data is running
through the LAN port.
o WLAN: Turns on when wireless is enabled and blinks during wireless transmission
occur.
o PWR: Indicates the unit is powered on.
• Reset Button (unscrew cap)
o Reboot: Press and hold the reset button for 2 seconds to restart the unit. All LEDs
except PWR will turn off before the unit turns back on and wireless transmission
occur.
o Reset – Press and hold the reset button for more than 10 seconds to restore the
unit back to factory default settings.
• PoE Port (unscrew cap) – Connect the network cable that is connected to the
provided PoE injector to power and configure the unit.
