Applications
TEW-738APBO is multiple mode system which can be configured either as a wireless
gateway or an access point as desired. It also can be used as a WDS link for Ethernet
network expansion. This section depicts different applications on Router AP Mode, AP
Mode, WDS Mode, CPE Mode, Client Bridge + Universal Repeater Mode and CPE + AP
Mode.
AP Mode (including Access Point + WDS)
An access point can be either a main, relay or remote base station. A main base
station is typically connected to a wired network via the Ethernet port. A relay base
station relays data between main base stations and relay stations or remote base
stations with clients. A remote base station is the end point to accept connections
from wireless clients and pass data upwards to a network wirelessly.
Example 1: Access Point without WDS
• It can be deployed as a tradition fixed wireless Access Point
Example 2: Access Point with WDS
• It can be deployed as a tradition fixed wireless Access Point and provides WDS link
to expand network
