TK-802R_TK-1602R Rack Mount KVM Switch User’s Guide July,2004
Page 23
Chapter 3 Operation
<Next Higher Bank> (when daisy-chained)
Front Panel Button
Press the corresponding button.
Hotkeys
Next bank =
OSD
While the OSD is activated on the console screen, press the Page Down key to
rotate through the bank selection incrementally.
<Autoscan Beep Sound On/Off>
While Autoscanning, a beep sound will serve to confirm channel switching. If you
want to turn on/off this beeping, then try the following hotkey sequence.
Note that while you are switching channel manually either by hotkey or front-panel push
button, the beep sound is always on, and cannot be turned off.
Hotkey
Beep sound on/off =
<Reflash EEPROM>
While you can freely change the computer names, autoscan time as well as
password, there might be times when you want to restore the switch to its default
factory settings. If this is the case, you can always press the hotkey sequence for
an EEPROM Reflash.
Note that Reflash EEPROM will not affect your password setting, thus won’t compromise
your KVM Switch access security.
Hotkey
Reflash EEPROM =
As soon as the hotkey sequence is executed, the following OSD screen dialog
appears to prompt you for a confirmation. Press Enter to confirm the EEPROM
Reflash directive.
REFLASH EEPROM ? ( YES )
ESC QUIT Ent er SELECTESC QUIT Ent er SELECT
Note that, except the hotkey sequence ScrLk + ScrLk + R, there is no option on the OSD Main
Menu to evoke the OSD Reflash function.
Scr
L
