Diagnostic LEDs
LED
Color
Sequence
Definition
PWR
(Power)
Green
Solid
Device is powered on
Green
Blinking
Powerline synchronization in
progress
N/A
Off
Devide is powered off
PL
Green
Solid
Powerline connected (Best)
(Powerline)
Blinking
Data transmission over Powerline
(Best)
Amber
Solid
Powerline connected (Better)
Amber
Blinking
Data transmission over Powerline
(Better)
Red
Solid
Powerline connected (Good)
Red
Blinking
Data transmission over Powerline
(Good)
N/A
Off
Powerline is not connected or
synchronized.
ETH
Green
Solid
Network connection established
(Ethernet)
Green
Blinking
Data transmission through network
port.
N/A
Off
Network standby or no network
connection.
Powerline Connections: Powerline (PL) LED color indicates the strength and
quality of the Powerline connection through the electrical system. The following
factors may affect the Powerline network’s connection quality:
• Noise – Generated by appliances which use your electrical system (e.g.
Microwaves, ovens, hair dryer, irons, dishwashers, etc.). The quality of your
household electrical wiring may also cause additional noise on your electrical
system.
• Distance – Long lengths of electrical wiring through your electrical system
between connected Powerline Adapters.
