14
CHAPTER 5
CHAPTER 5 - ACVMAX OPERATION
5.4. Status Line Messages
Standby - Indicates that the Prestige is ready to re-
spond when a demand is received.
CH Demand - A central heating call has been received.
DHW Demand - A domestic hot water call has been
received.
CH/DHW Demand - Central heating and domestic hot
water calls are being received simultaneously. Both calls
are being satised simultaneously because domestic
hot water priority has been disabled.
DHW Priority - Central heating and domestic hot wa-
ter calls are being received simultaneously. Domestic
hot water call is being satised rst because it has prior-
ity over central heating calls.
Priority Timeout - Central heating and domestic hot
water calls are being received simultaneously. The do-
mestic hot water priority time limit has been exceeded.
Priority will now switch back and forth between central
heating and domestic hot water calls until one call is
satised.
External Demand - An external modulation call has
been received.
Slave Operation - The Prestige is a slave in a cascade
system.
Manual Operation - The burner or circulators have
manually been enabled in the Installer Menu.
CH Burner Delay - The burner will not re until the call
blocking time has elapsed.
DHW Burner Delay - The burner will not re until the
call blocking time has elapsed.
CH Setpoint Reached - The burner is not red because
the supply/system water temperature exceeds the set-
point. The central heating circulator(s) continue(s) to
operate and the burner will re again once the supply/
system water temperature drops below the setpoint.
DHW Setpoint Reached - The burner is not red be-
cause the supply/system water temperature exceeds
the setpoint. The domestic circulator(s) continue(s) to
operate and the burner will re again once the supply/
system water temperature drops below the setpoint.
CH Post Pump - The central heating circulator(s) is/are
running to remove heat from the Prestige at the com-
pletion of a call.
DHW Post Pump - The domestic hot water circulator(s)
is/are running to remove heat from the Prestige at the
completion of a call.
Freeze Protection - The burner is red because the
freeze protection feature has been activated. Freeze
protection will end once the supply/system water tem-
perature is raised to 60°F [16°C].
Boiler Protection - The burner ring rate is being re-
duced because of an excessive dierence between the
boiler supply and return temperatures. The ring rate
will begin increasing once the temperature dierence
is less than 45°F [25°C].
Low Water Pressure - The system pressure has dropped
to 10.1 psi. The Prestige will still respond to calls until
the pressure drops below 7.2 psi. Increase system pres-
sure to 14.5 psi to clear Low Water Pressure warning.
Lockout Description - The lockout which currently
has the Prestige shut down is displayed.
