TriangleTube Instinct Series User Manual

21
CHAPTER 5
Low Water
Water pressure has fallen below
an acceptable operating level.
Increase pressure to normal
range. Boiler will automatically
reset once water level returns to
normal.
If problem persists,
call for service
E37
5.10.1 Lockout Screen
If a problem occurs, the Lockout Screen replaces the Home Screen. The backlight will remain on until the lockout
is reset.
Pressing any arrow button will return to the Home Screen so that additional troubleshooting can be performed. See
Sections 5.10.2 on page 22 and 5.10.3 on page 23 for a list of lockouts and descriptions.
CHAPTER 5 - ACVMAX OPERATION
The lockout message is displayed at the top of the screen
The rst sentence gives a
description of the lockout.
The second sentence gives a
possible cure for the lockout.
The third sentence tells how
to reset the lockout
The lower right corner displays
the lockout reference code
Low Water
186°F
156°F
Target = --
Solo
Press any ARROW Button
Press any ARROW button to
return to the Home Screen
while locked out.
The Main Menu can then be
entered from the Home Screen
to help diagnose the problem.
Select the Home Screen icon
at the bottom of any menu
screen to return to the Lockout
Screen.
The status line now displays the lockout
