FMS-2000M
LIT-12013578
14
Figure 8: Standard remote pressure sensor 9-pin side view
Monitored spaceReference space
Table 4: Remote pressure sensor installation components
Number Description
1 
2 Stainless steel flow tube mounting plate
3 
4 Flow tube
5 Stainless steel mounting plate
6 
7 Louvered cover plate
8 Remote pressure sensor
9 Mounting bracket
10 Terminal block
11 Thin silicone caulking
