FMS-2000M

LIT-12013578

BMS integration

Conguring the display module settings

FMS-2000M DIP switch position Demo mode Run mode

Position 1 On On

Position 2 On On

Position 3 Off On

Position 4 On Off

Table 17: 

Objects Analog inputs Read/Write Availability of analog input objects

FMS2M-Bx1x FMS2M-Bx2x FMS2M-Bx3x FMS2M-Bx4x

AI-1 Analog input 1, differential pressure Read only Yes Yes Yes Yes

AI-2 Analog input 2, differential pressure Read only No Yes Yes Yes

AI-3 Analog input 3, differential pressure Read only No No Yes Yes

AI-4 Analog input 4, differential pressure Read only No No No Yes

Note: In the following tables, the abbreviation NV refers to network variable (NV).

Objects Binary inputs Read/Write Availability of binary input objects

FMS2M-Bx1x FMS2M-Bx2x FMS2M-Bx3x FMS2M-Bx4x

BI-1 Digital input 1, door switch 1 Read only Yes Yes Yes Yes

BI-2 Digital input 2, door switch 2 Read only No Yes Yes Yes

BI-3 Digital input 3, door switch 3 Read only No No Yes Yes

BI-4 Digital input 4, door switch 4 Read only No No No Yes

Objects Analog values Read/Write Availability of analog value objects

FMS2M-Bx1x FMS2M-Bx2x FMS2M-Bx3x FMS2M-Bx4x

AV-1 NV Temperature 1 Read or write Yes Yes Yes Yes

AV-2 Low alarm setpoint 1 Read or write Yes Yes Yes Yes

AV-3 Low warning setpoint 1 Read or write Yes Yes Yes Yes

AV-4 High warning setpoint 1 Read or write Yes Yes Yes Yes

AV-5 High alarm setpoint 1 Read or write Yes Yes Yes Yes

AV-6 NV Humidity 1 Read or write Yes Yes Yes Yes

AV-7 NV Temperature 2 Read or write No Yes Yes Yes

AV-8 Low alarm setpoint 2 Read or write No Yes Yes Yes

AV-9 Low warning setpoint 2 Read or write No Yes Yes Yes

AV-10 High warning setpoint 2 Read or write No Yes Yes Yes

AV-11 High alarm setpoint 2 Read or write No Yes Yes Yes

AV-12 NV Humidity 2 Read or write No Yes Yes Yes

Table 18: Analog inputs for integration in a BMS

Table 19: Binary inputs for integration in a BMS

Table 20: Analog values for integration in a BMS
