FMS-2000M
LIT-12013578
16
Figure 10: 24 VAC to 24 VAC isloation transformer
Table 6: 24 VAC to 24 VAC isloation transformer
Item Description
1 
2 
3 Isolation transformer, 24 VAC to 24 VAC, 30 VA
4 
5 1 A slow blow fuse
6 Class 2, Limited Energy, or LPS isolated power supply wiring in this compartment
