Triax SR 110 - Table of Contents

2
Table of Contents
Table of Contents 2
Table of Contents continued 3
Receiver Overview 4
Remote Control 5
Layout Features 6
Foreword 7
Safety Instructions 8
Safety Instructions: Continued 9
Correct Handling of Batteries 10
Explanation of the safety instructions 11
Contents Supplied 12
Description 13
Pre-Programmed Satellites 14
Pre-Programmed Satellites Continued 15
Connecting the receiver 16
Fitting the satellite cable 17
Fitting the satellite cable Illustration 18
Scart cable connection 19
Phono / AV Cinch cable connection 20
Connection of a digital audio receiver 21
Aligning the satellite dish 21-25
Remote Control 26
Receiver 27
Screen fade-in during programme change 28
User interface on TV screen 29
Menu structure 30
Navigating through the menus 31
Channel (symbol: TV set) 32-33
49
Receiver Receiving decoder that converts the IF satellite signals
into video and audio signals.
SCART 21-pin connector to connect the TV set to the receiver.
Swap function Swap between the current and last viewed
programme.
Transponder Satellite bandwidth 27MHz wide which several digital pro-
grammes can be broadcast simultaneously on one
transponder.
VCR Abbreviation for Video Cassette Recorder.
Glossary continued
Warranty Period
This product has a 12 month guarantee from the date of purchase. In the unlikely event
of any issues during this period, please return to the installer / retailer with your proof of
purchase.
