6
Layout Features
NO Symbol Explanation
1 Standby Switching on and standby mode
2 0-9 Select programme directly, number input
3 FAV Display own favourites list
4 TV/ Radio Switch between TV mode and Radio mode
5 TV / SAT Switch between normal and satellite dish
6 OK In normal operation: display current programme list. In the
menu: confirm menu item
7 V- Reduce volume / Cursor movement to the left
8 Back Quit menu or menu item
9 INFO Display of the current programme’s reception data (Sat-finder
function)
10 Mute Mute sound setting
11 Timer Display Timer
12 Recall Change to the previously selected programme
13 Zoom increase picture size Freeze picture
14 CH ▲ Change to next higher programme position/Cursor movement
upwards
15 List Display TV programme listings
16 V+ Increase volume / Cursor movement to the right
17 Menu Display main menu
18 CH ▼ Change to next lower programme position / Cursor movement
downwards
19 EPG Electronic Programme Guide Now and Next
20 Text Display teletext
21 M/P Multi-picture function, display picture preview
22 Audio Change audio mode
45
Receiver
Dimensions in mm (W × D × H) 280 × 157 × 44
Weight in grams, approx. Receiver 1100 g
Remote control unit 80 g (less batteries)
Input frequency range 950 MHz ~ 2150 MHz
IF Band width 55 MHz/8 MHz (below 5MS/s)
LNB power supply 13/18 V, 0.30 A max.
Spikes overload protection
LNB control 22 KHz ± 2 KHz, 0.6 V pp ± 0.2 V
DiSEqC control Version 1.0, Version 1.2, Tone-Burst
A/B
Symbol rate 1 ~ 35 MS/s
Bit current MPEG-2 ISO/IEC 115200 Bit current
specification
Input speed Max. 15 Mbit/s
Error correction (FEC) 1/2, 2/3, 3/4, 5/6, 7/8, auto
Video MPEG-2 MP@ML
Audio MPEG -1/2 Audio layer 1 or layer 2
Height / width ratio 4:3 Letterbox, 4:3 Pan Scan, 16:9
Video resolution 720 x 576 (Pal), 720 x 480 (NTSC)
Audio mode Left, right, stereo, AC3 digital sound
Connection options
LNB IF input Type F, IEC 169-24
TV-SCART (output only) Video CVBS, Audio L, R
VCR-SCART (output and input) Video CVBS, Audio L, R
RCA (CINCH) Audio L,R
SPDIF, COAXIAL Digital audio output
Technical Specification
