UPM 1400
9 EN
Main menu
Description of the menu items
Satellite:
• TP search: search for signals on a satellite, by transponders, etc…
• SAT identification: auto recognition of the received satellite
• Packet control: simultaneous measurements of multiple transponders in real time
• DiSEqC search: identification of received satellites in multi-satellite systems, switched BIS
• Motor: motor parameters for motorized satellite systems
• Spectrum: analysis and evaluation of received signals
Terrestrial:
• TP search: search for DVB-T/T2 multiplexes
• Constellation: graphical representation of the signal
• Packet monitoring: simultaneous measurement of multiple transponders in real time after
searching the entire bandwidth
• Spectrum: analysis and evaluation of the received signal
Cable:
• TP search: search for DVB-C multiplexes
• Constellation: graphical representation of the signal
• Packet monitoring: simultaneous measurement of multiple transponders in real time after
searching the entire bandwidth
• Spectrum: analysis and evaluation of the received signal
TV:
• Display of live TV images in DVB-S/S2, DVB-T/T2 and DVB-C
• Data display
• Manual search for SAT, TER, Cable programs in the list of channels
• When the program is displayed, pressing MENU gives access to:
▪ Silence (mute key)
▪ Info: general information on the program received in addition to its video (Signal,
Quality, MER, SNR, CBER, VBER, frequency, band received, etc.)
▪ PVR: recording
Setting parameters:
• System settings: (language, unit of measurement, …)
• OSD setting: display settings
• Clock
• Reset (allows user to erase the lists of received channels)
• Color settings: brightness, contrast, etc…
• Screen adjustment: backlighting,
• System info: device general information
Advanced:
• USB: access to USB media if connected
• Download FTP and PING: unused network function
