occurs to the one of the power source, the redundant power supply will start running
automatically to ensure un-interruptible operation.
Controlling and Management
The Video-Wall processor controlling software allows users to manage and control the
processor on PC. It supports Windows2000/XP/Vista/7/8. The Video-Wall processor and
controlling PC can be connected by using CAT5/6 cable(TCP/IP) or RS232 cable. The
software can also control up to 4 extra traditional matrix switchers when they are
cascade(RS232) to the processor.. The Video-Wall processor can also be controlled by
employing the specific controlling keyboard(RS232).
System Diagram of Video-Wall Processor
3. Specifications
3.1 Input card
3.1.1 Input Port - VGA
