Tricolor Video-Wall Processor 380 - Creating a Window

Parameters
Screen_ID
The video-wall ID
Total_line
Total lines of one frame
Total_pix
Total pixel clocking of one line
Act_vpos
The vertical starting point of the active line
Act_vsize
Total number of active lines of one frame
Act_hpos
The horizontal starting point of the active pixel
Act_hsize
Total number of active pixel of one line
Hs_width
Width of horizontal synchronization
Vs_width
Height of vertical synchronization
Dis_freq_h
the integer part of pixel clock frequency
Dis_freq_l
the fractional part of pixel clock frequency
Hsync_pol
The polarity of horizontal polarity
Vsync_pol
The polarity of vertical polarity
【Examples】
1.<sset,0,806,1344,35,768,296,1024,136,6,65,0,1,1> //1024x768
2.<sset,0,1066,1688,41,1024,360,1280,112,3,108,0,0,0> //1280x1024
3.<sset,0,795,1792,24,768,368,1360,112,3,85,32768,0,0> //1360x768
4.<sset,0,1089,1864,36,1050,378,1400,144,4,121,49152,0,0> //1400x1050
5.<sset,0,934,1904,31,900,384,1440,152,6,106,46622,0,0> //1440x900
6.<sset,0,1250,2160,48,1200,496,1600,192,3,162,0,0,0> //1600x1200
7.<sset,0,1089,2240,35,1050,456,1680,176,6,146,0,0,0> //1680x1050
8.<sset,0,1125,2200,41,1080,192,1920,44,5,148,32768,0,0> //1920x1080
9.<sset,0,1235,2080,31,1200,118,1920,32,6,154,0,0,0> //1920x1200
10.<sset,0,750,1650,25,720,260,1280,40,5,74,16384,0,0> //1280x720
3. Creating a window
Instruction
format
<open, Screen_ID, W_ID, SourceCh, src_hstart, src_hsize, src_vstart, src_vsize,
x0,.y0, x1,y1>
Function
To create a new window of the specified video-wall
Parameters
Screen_ID
The video-wall ID
W_ID
The ID of the window to be created
SourceCh
The input channel which used as the signal source of the window
src_hstart
The horizontal starting pixel of the signal source
src_hsize
The horizontal ending pixel of the signal source . If the value is 0,
means the original horizontal size of the signal source, and the
src_hstart is useless
src_vstart
The vertical starting pixel of the signal source
src_vsize
The vertical ending pixel of the signal source . If the value is 0,
means the original vertical size of the signal source, and the
src_vstart is useless
