e-PAD Configurations:
SECURE OPERATIONS ARE DEPENDENT ON SYSTEM CONFIGURATION. After
entering the access code, one must press a 6
th
digit to unlock specific doors or perform an
operation according to the following listing.
6
th
Button Press Operation
• Configuration A [SW 1 off / SW 2 off]:
o Button (1/2): Unassigned
o Button (3/4): Unlocks all entry and compartment doors
o Button (5/6): Unassigned
o Button (7/8): Activates zone 6 unidirectional actuation
o Button (9/0): Toggles Aux 1 output
• Configuration B [SW 1 off / SW 2 on]:
o Button (1/2): Unlocks all entry door(s)
o Button (3/4): Unlocks all entry and compartment doors
o Button (5/6): Unassigned
o Button (7/8): Activates zone 6 unidirectional actuation
o Button (9/0): Toggles Aux 1 output
• Configuration C [SW 1 on / SW 2 off]:
o Button (1/2): Unlocks all entry doors
o Button (3/4): Unlocks all doors assigned to relay bank A
o Button (5/6): Unlocks all doors assigned to relay bank B
o Button (7/8): Unlocks all doors assigned to relay bank C
o Button (9/0): Unlocks all doors assigned to relay bank D
• Configuration D [SW 1 on / SW 2 on]:
o Button (1/2): Unlocks all entry doors
o Button (3/4): Unlocks all entry and compartment doors
o Button (5/6): Unlocks all curb side compartment doors (relay banks C-D)
o Button (7/8): Unlocks all driver side compartment doors (relay banks A-B)
o Button (9/0): Toggles Aux 1 output
See the table on page 6 for S2 DIP switch assignments.
e-PAD / e-FOB Dome/Porch Light Activation:
The dome/porch light is activated for a timed duration (5-60 seconds) whenever a keypad
button is pressed or when system is unlocked from FOB transmitter or vehicle switch. The
time duration is dependent on the trim pot A setting (see page 6). The dome/porch light is
deactivated with starting the engine.
e-PAD Protective Deactivating Security Feature:
After repeated entry of incorrect codes (20 button presses without enabling), the keypad is
deactivated for 1 minute. This helps prevent unauthorized access by entering random
codes. No beep will sound with button press while the system is disabled.
