e-PAD Operation and Features
The e-PAD is shipped with default Authority and Access codes. When all necessary wiring
connections are made, the e-PAD system will function as indicated below. Unless the OEM
or dealer has changed default codes, the Authority and Access codes are as follows:
Access code:
Digit 1 Digit 2 Digit 3 Digit 4 Digit 5
1 / 2 3 / 4 5 / 6 7 / 8 9 / 0
Authority code:
Digit 1 Digit 2 Digit 3 Digit 4 Digit 5
7 / 8 7 / 8 7 / 8 7 / 8 7 / 8
Locking doors with keypad:
Regardless of the configuration of the system, e-PAD locking operation (lock all doors) is
accomplished by pressing and holding down the first button (1 / 2) for 1-2 seconds. An
access code is not needed to lock the doors.
Unlocking doors with keypad and other secure operations:
After access codes have been assigned secure e-PAD
operations can be accomplished by
enabling the keypad. The keypad is enabled by entering a valid 5-digit access code. After
entering an access code, the keypad is enabled for 5 seconds and a sixth button press
initiates a secure operation, such as door unlocking or other operations. Entering the correct
access code alone will not initiate a secure operation.
The following sequence illustrates how to perform secure operations with e-PAD.
• Enter a valid 5-digit access code (see default access code information above and
page 15). Confirmation beeps indicate the system is enabled.
• Press the (3 / 4) button within 5 seconds and all doors will unlock.
If an unassigned button or no button is pressed while the system is enabled, the keypad
reverts back to disabled state.
The e-ASK
system can be configured in 1 of 4 ways, as defined by #1 and #2 DIP Switch
settings on I/O module (see page 4 for e-PAD configuration information). The secure keypad
operations are set depending on system configuration.
