TriMark e-ASK - Wiring Color Code Tables and Diagrams; RF Receiver Assignments

Page 9 of 16
Wiring color code tables and diagrams--The following tables and
diagrams are provided to show color-coded wire and pin assignments for the e-ASK
system.
TABLE 1: RF RECEIVER ASSIGNMENTS
WIRE COLORS J11 – 14-PIN HARNESS
PURPLE / WHITE
CARGO UNLOCK BUTTON INPUT/OUTPUT. BUILT-IN RELAY, 12A.
1
PURPLE / WHITE 2
WHITE / GREEN
LOCK OUTPUT (N/C RELAY 30)
3
WHITE / BLACK
LOCK INPUT (N/C RELAY 87A)
4
YELLOW
CONNECT FOR TEACH REMOTE FOB
5
BLACK
GROUND
6
BROWN
UNASSIGNED
7
RED +12 VDC POWER SOURCE. 8
BLUE / WHITE
UNLOCK INPUT (N/C RELAY 87 A)
9
WHITE / RED
UNLOCK OUTPUT (N/C RELAY 30)
10
PINK / BLACK
LOCK / UNLOCK POLARITY (N/O RELAY 87)
11
WHITE
UNASSIGNED
12
PINK
UNASSIGNED.
13
PINK
UNASSIGNED
14
WIRE COLORS
10-PIN HARNESS
ORANGE
UNASSIGNED 1
WHITE / BROWN
UNASSIGNED 2
BROWN / WHITE
CARGO LOCK AUX. 3
WHITE / YELLOW
UNASSIGNED 4
GRAY
UNASSIGNED 5
PURPLE / GREEN
UNASSIGNED
6
WHITE / BLUE
UNASSIGNED
7
BLUE
UNASSIGNED
8
GREEN
UNASSIGNED
9
PURPLE
UNASSIGNED
10
WIRE COLORS
4-PIN HARNESS
WHITE / RED
UNLOCK INPUT FROM INTERIOR SWITCH
2
WHITE / GREEN
LOCK INPUT FROM INTERIOR SWITCH
4
0.250 MALE CONNECTORS
CN2 & CN3
BUILT-IN STARTER KILL RELAY. NON-POLARIZED. 40A
* DO NOT USE A TEST LIGHT ON THE MODULE'S 500mA OUTPUTS
