Communication Module | Комуникационен модул | Komunikační modul |
Kommunikationsmodul | Kommunikationsmodul | Μονάδα επικοινωνίας | Módulo
de comunicación | Sidemoodul | Tiedonsiirtomoduuli | Module de communication
| Komunikacijski modul | Kommunikációs modu | Modulo di comunicazione | Ryšio
modulis | Sakaru modulis | Communicatiemodule | Moduł komunikacyjny | Módulo
de comunicação | Modul de comunicare | Komunikačný modul | Komunikacijski
modul | Kommunikationsmodul
06
WiFi Kit, Bluetooth, Wi-Fi/LAN Kit module: optional
No. Color BMS Smart Meter EMS
1 Orange&White 485_A2 NC 485_A
2 Orange NC NC 485_B
3 Green&White 485_B2 485_B1 485_A
4 Blue CAN_H NC NC
5 Blue&White CAN_L NC NC
6 Green NC 485_A1 485_B
7 Brown&White NC 485_B1 NC
8 Brown NC 485_A1 NC
Smart
Meter
Battery
To Smart Meter
To EMS device
To Battery
To Next Page
