106
ET Series and ET Plus+ Series
1
2
......
3
4
5
CTA
CTB
CTC
E-BAR
6
To Smart Meter
BACK-UP Loads
Loads
Loads
Grid
Power Meter
DC Isolator
AC Breaker
AC Breaker
AC Breaker
AC Breaker
To Battery
Battery
PV String
L1 L2 L3 N PE
The E-N link applies to Australia, New Zealand, South Africa etc. Please refer to local regulations.
ON OFF
Australia only.
