ACCUVAR - Operational Manual
Operational Details
The KVAR Based Controller for LT Capacitor Banks, ACCUVAR is a versatile meter, with all the
features needed to implement a robust electrical load management system. It can be configured
to suit most PF control needs and this is achieved by making as many parameters field
programmable as possible.
There are basically two modes of operation in ACCUVAR:
1. Programming Mode
2. Run Mode
After supplying power (80 VAC - 480 VAC), the unit displays immediately power on display
message and by default, the display comes into Run Mode such as shown below.
Now, the unit can be operated by using the following keypad provided for both the Programming
Mode and Run Mode.
Press key for about five seconds continuously, to go from Run mode to Programming
Mode. The first screen in this mode is:
To Next Page
