Trinity ACCUVAR User Manual

pg. 8
TRINITY
ACCUVAR - Operational Manual
Technical Specifications
Parameter
Type
Name
Statistics
Supply
Three Phase and Neutral of a 3P4W system
Voltage
Direct Voltage Input : Up to 300V L-N
Burden : 0.5VA
Current
Secondary Current Input : 5A or 1A
CT Ratio : Site Selectable
Range of Reading : 5 - 5000A
Burden : < 1.0VA
Overload : 5A CT = 6A RMS Continuous
: 1A CT = 1.2A RMS Continuous
Power Supply
Self Powered from mains. Wide operating Voltage SMPS:
80 VAC - 480 VAC, 45-65 Hz.
Relay
Switching Voltage : Max. 250 VAC
Switching Power : Max. 1000W
Expected Mechanical Life : >10 x 10
6
switching operations.
Expected Electrical Life : >4 x 10
6
switching operations.
@(Load = 200VA, Cos Ø = 0.5)
INPUT
OUTPUT

Trinity ACCUVAR Specifications

General

Brand	Trinity
Model	ACCUVAR
Category	Controller
Language	English
