15
CHASSIS MOUNTING DIMENSIONS (LOOKING FROM REAR)
To mount the controller onto a back plane, remove the 2 mounting clips (included in box) and insert one at the top rear of the
case, by tting the small tab into the rectangular slot and x with the M3 x 6mm screw provided.
The second clip ts to the bottom of the case rear. Line up the DIN rail lever with the hole and slot in the metal chassis, t the
clip into the slot and x it with the M3 x 10mm screw.
ENSURE THAT THE VENTILATION SLOTS AT THE TOP AND BOTTOM OF THE MC664 ARE KEPT CLEAR TO ENSURE A
FREE FL
O
W O
F A
IR THR
OU
GH THE MO
D
ULE.
X X X
195mm
