TpH // Annex
FSM Control RW 5000 Uint16 FSM control register (calibration).
FSM Parameter RW 5001 Uint16
FSM parameter register (calibration). Contains parameter
index and calibration method.
• 0x0001: pH
• 0x0103: Temperature
FSM Status R 5002 Uint16 FSM status register (calibration).
Permanent errors R 5100 Uint16 Permanent errors (bit eld).
Permanent warnings R 5101 Uint16 Permanent warnings (bit eld).
Temporary errors R 5102 Uint16 Temporary errors (bit eld).
Temporary warnings R 5103 Uint16 Temporary warnings (bit eld).
Calibration Control RW 6000 Uint16
Calibration control register. For complete restoration of
calibration (pH and temperature):
• 0x0001: Factory calibration
• 0x0002: Last calibration
Factory calibration - Parameter RW 6001 Uint16
Parameter index of the following calibration data (factory
calibration):
• 0x0000: pH
• 0x0001: Temperature
Factory calibration - Oset RW 6002 Float Oset of the factory calibration to the selected parameter.
Factory calibration – Scaling RW 6004 Float
Scaling factor of the factory calibration to the selected
parameter.
Factory calibration – Square RW 6006 Float
Square coecient of the factory calibration to the selected
parameter.
Not used, always 0.
Factory calibration – Timestamp RW 6008 Uint32 Time of factory calibration.
Active calibration - Parameter RW 6010 Uint16
Parameter index of the following calibration data (active
calibration):
• 0x0000: pH
• 0x0001: Temperature
Active calibration – Oset RW 6011 Float Oset of the active calibration to the selected parameter.
Active calibration – Scaling RW 6013 Float
Scaling factor of the active calibration to the selected
parameter.
Active calibration – Square RW 6015 Float
Square coecient of the active calibration to the selected
parameter.
Not used, always 0.
Active calibration – Timestamp RW 6017 Uint32 Time of active calibration.
