Requirements and notes Functionality Function
code
Register Value Length FSM
Status
Type Result
Notes:
Now poll readings
to check if values are
satisfying.
Poll temperature data 0x03 1002 2 IEEE
754
Float
Calibration isn't saved
yet.
If you leave calibration
process or power down
between step 1 and 5,
the calibration is lost.
Step 4
Requirements: Save Calibration
Calibration process
succeeded
Save Calibration and wait for
FSM Status to get 11
0x06 5000 0x0109
Check read FSM Status register
until FSM Status gets 11
0x03 5002 1 11 Integer
Set FSM Status to 2 again 0x06 5000 0x0102
Check read FSM Status register
until FSM Status gets 2
0x03 5002 1 2 Integer
Calibration is saved.
Step 5
Notes: Leave Calibration process 0x06 5000 0x0000
If done between calibra-
tion steps, calibration is
aborted.
Check read FSM Status register
until FSM Status gets 0
0x03 5002 1 0 Integer LED gets
green
