Probe Functions and Indications
(A) Tone tracing
1) Set the〝Trace/Hub blink〞 selector to〝Trace〞 ↓
position.
2) Push〝Trace〞 button and the probe end becomes
active.
3) Hold〝Trace〞 button to trace a line or plug the
probe’s RJ45 jack into a wall outlet or patch panel
port using a jumper cable.
4) The tone is loudest when the tip of the tracer is
near and parallel to the cable carrying the tone
signal.
*Application Hint: To detect tracing tone signal at patch panel.
For the best signal, using
a patch cable, one end
connect to Net Probe Pro
RJ45 jack, then use the
other end patch cable
connect or touch the
patch panel port.
(B) Signal strength LED
Touch the tip of the Probe to the insulation of each suspect
wire/cable, when the tip touches the right cable, the tone will
be at its loudest and the〝Signal〞LED will turn on. (You
may turn the volume down as the tip gets nearer to the right
cable to help distinguish between the cables and the tip
touch.)
