Frequency compatibility 50 Hz
Output watts 1000
Continuous output capacity (watts) 1000
Peak output capacity (watts) 2000
Output nominal voltage 230V
Output voltage regulation Nominal 230v +/- 5% until LBW. Peak coltage 360v
Output frequency regulation 50/60 Hz (+/- 0.5 Hz)
Overload protection Includes 15A input breaker dedicated to the charging system and 15A output breaker for AC output loads
Outlet quantity / type Hardwire
INPUT
Nominal Input Voltage(s) Supported 230V AC
Recommended Electrical Service
DC INPUT: Requires 12VDC input source capable of delivering 240A for the required duration (when used at full
continuous capacity - DC requirements increase during OverPower and DoubleBoost operation). For automotive
applications, professional hardwire installation with 400A minimum battery system fusing is recommended.
Maximum input amps / watts
DC INPUT: Full continuous load - 240A at 12VDC. AC INPUT: 17 amps at 230VAC with full inverter and charger
load (8.7A max charger-only / combined input load to support charger and AC output is automatically controllable to
66%-33%-0% based on AC output loading using the charger limiting set points - see manual for setting instructions)
Input connection type DC INPUT: Set of 2 DC bolt-down terminals. AC INPUT: Hardwire via built in junction box with cover plate
Voltage compatibility (VAC) 230
Voltage compatibility (VDC) 12
BATTERY
Expandable battery runtime Runtime is expandable with any number of user supplied wet or gel type batteries
DC system voltage (VDC) 12
Battery charge Includes 4/40 amp DC charging system adjustable.
LEDS ALARMS & SWITCHES
Alarms Audible status indicators 10.5V (low battery)/21V start alarm
Switches
The inverter provides a RJ-45 port for optional
APSRMSW
remote control. RJ45 port operates with standard RJ485
interface (APSRMSW sold separately)
Front panel LEDs Set of front panel LED's display inverter status, charger status, as well as battery voltage status
PHYSICAL
Unit Dimensions (HWD/in) 7.25 x 8.75 x 18
Unit Dimensions (HWD/cm) 18.41 x 22.22 x 45.72
Unit weight (lbs) 35.5
Unit weight (kg) 16
Cooling method Fan
