Installation
Note: Make sure the power to all devices is turned off prior to installation. You must
unplug the power cords of any computers that have the Keyboard Power On Function.
1. Plug your USB keyboard, mouse and DVI monitor into the console ports
on the unit.
Note: If using a wireless keyboard and mouse, the dongle must plug into the unit’s
keyboard port in order to use the hotkey function.
2. (Optional) A USB 2.0 hub can be connected to the USB console mouse
port, allowing you to add multiple USB peripherals to your installation.
Note: To ensure proper functionality, use a hub with an external power supply. Also,
the KVM’s Mouse Emulation Mode must be disabled (see the Keyboard Hotkey
Commands section of this manual for details) when connecting a hub.
3. (Optional) Plug your speakers and/or microphone into the audio jacks on
the side of the unit.
4. Plug the connectors of the built-in cables into their respective ports on
the computers you are installing.
5. Power on your devices.
Note: The unit’s power on default is to link to the first computer that is powered on.
17-10-486-933633.indb 4 11/17/2017 2:44:37 PM

Tripp Lite B032-DUA2 Specifications

General

Console ports	3.5mm headphone
Audio connections	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of computers controlled	2
Certification	CE, FCC, REACH
Product color	Black
Sustainability certificates	RoHS
Built-in display	No
Number of users	1 user(s)
Cables included	Audio (3.5mm), DVI, USB
Package depth	238.8 mm
Package width	170.2 mm
Package height	61 mm
Package weight	590 g
Country of origin	China
Master (outer) case width	497.1 mm
Master (outer) case height	196.1 mm
Master (outer) case length	327.9 mm
Master (outer) case weight	7080 g
Harmonized System (HS) code	8471.80.1000
Quantity per master (outer) case	10 pc(s)
Master (outer) case GTIN (EAN/UPC)	10037332200362
