Inverter/Charger DC Volt: 12
Twin 00 (2/0)
Watts 6 4 2 0 00 (2/0) (RV2012OEM & RV3012OEM only)
500 15 ft 25 ft 39 ft 62 ft 79 ft 158 ft.
700 11 ft 18 ft 28 ft 44 ft 56 ft 112 ft.
1000 N/R 12 ft 20 ft 31 ft 39 ft 78 ft.
2000 N/R N/R N/R 16 ft 20 ft 40 ft.
2400 N/R N/R N/R 13 ft 16 ft 32 ft.
3000 N/R N/R N/R 10 ft 13 ft 26 ft.
†
N/R = Not Recommended. NOTE: Acceptable power is directly related to cable length (i.e. - the shorter the cable, the better the performance)
Minimum Recommended DC Cable Sizing Chart
†
Use in conjunction with DC wiring connection instructions in the Battery Connection section.
Specifications
(English)
Model Number: RV750ULHW RV1250ULHW RV2012UL RV2012OEM RV3012OEM
Series Number: AGAP5088 AGAP5094 AP5626 AGAP200012MVP3 AGAP4669
AC Input Connection: Hardwire Hardwire Hardwire Hardwire Hardwire
INVERTER
Common Specifications for All Models: •
DC Input Volts (Nominal): 12 VDC • · DC Input Voltage Range: 10 - 15 VDC • Output Volts (Nominal): 120 VAC, ± 5% • Output Frequency (Nominal): 60 Hz, ± 0.5% • Efficiency: 88% to 94%,
depending on load and temperature
Tripp Lite Inverter/Chargers include a Battery Charge Conserver (Load Sense) Control which saves battery power by allowing users to set the minimum load level at which the unit’s
inverter turns on. Users can significantly reduce the No Load DC Input Current (approximately 1 to 3 A for all models) to a very low amp level with the use of this control.
Continuous Power (@ 20 C ): 750 1250 2000 2000 3000
OverPower
™
Peak Surge Power:* 1125 1875 3000 3000 4500
DoubleBoost
™
PeakSurgePower:* 1500 2500 4000 4000 6000
Maximum Output AC Current 6.3 A 10.4 A 16.7 A 16.7 A 25 A
Continuous
UL-Recognized DC Fuse 125 A 200 A two 175 A two 175 A two 275 A
Required
DC Input Current @
Nominal V DC Full Load: 73 A 117 A 190 A 185 A 282 A
BATTERY CHARGER
Common Specifications for All Models •
Acceptance Volts VDC: (Wet** / Gel) 14.4 V** / 14.2 V • Float Volts DC (w/gel): 13.3 V (13.6 V) • · Input Volts (Nominal): 120 VAC
Charging Capacity DC: 45 A** / 11 A 55 A** / 14 A 100 A** / 25 A 100 A** / 25 A 140 A** / 35 A
Input Current AC: 8.2 A 11 A 20 A 21 A 25 A
LINE VAC OPERATION
Common Specifications for All Models •
Input Frequency (Nominal): 60 Hz, ±10%
•
Maximum Input Volts (Transfer to Battery) 145 VAC Except OEM Models (Selectable 145V**/135V)
Minimum Input Volts: Selectable 75**, 85, 95 or 105 VAC Selectable 75**, 85, 95 or 105 VAC Selectable 75**, 85, 95 or 105 VAC Selectable 75**, 85, 95 or 105 VAC Selectable 75**, 85, 95 or 105 VAC
Transfer to Battery
Maximum Input AC Current 30 A 33 A 38 A 43 A 30 A
(Continuous, Charger at Maximum):
Maximum Bypass AC Current: 20 A 20 A 30 A 20/20 A 20/20 A
* OverPower duration (up to 1 hour). DoubleBoost duration (up to 10 seconds). Actual duration depends on battery age, battery charge level and ambient temperature. **Factory setting.
The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.
Wire Gauge vs. Maximum Distance from Unit to Battery
Note on Labeling Two symbols are used on the RV labels.
V~: AC Voltage V : DC Voltage
