Product Familiarisation
PRODUCT FAMILIARISATION
1. Speed Controller
2. Motor
3. Illuminated Power Switch with Lock-Out Cover
4. Handles
5. Collet
6. Dust Extraction Port
7. Plunge Lock Lever
8. Micro Winder
9. Turret Stops
10. Table-Winder Connection Point
11. Depth Stop Lock Knob
12. Safety Guards
13. Baseplate Mounting Knobs
14. Fence
15. Spanner
16. Extended Baseplate
17. Collet
18. Table Height Winder
19. Pivot Mount
1
3
4
6
13
8
5
11
15
2
7
9
14
10
12
16
17
18
19
