Contents / Specification
Thank you for purchasing this Triton tool. Please read these instructions: they contain information necessary for safe and
effective operation of this product. This product has a number of unique features and, even if you are familiar with similar
products, reading the instructions will help you get the full benefit of its unique design. Keep these instructions close to
hand and ensure all users of this tool have read and fully understand them.
CONTENTS
Specification 2
Product Familiarisation 3
Symbols 4
General Safety 4
Functions 6
Hand-Held Operation 7
Table-Mounted Operation 8
Maintenance 9
Troubleshooting 10
Guarantee 11
SPECIFICATION
Model no. JOF001
Voltage EU: 220-240V AC, 50/60Hz, 4.6A
SA: 220-240V AC, 50/60Hz, 4.6A
AU: 220-240V AC, 50/60Hz, 4.6A
JP: 100V AC, 50/60Hz, 10A
USA: 120V AC, 60Hz, 8.4A
Input power EU: 1010W
SA: 1010W
AU: 1010W
JP: 1010W
USA: 1010W / 1-
1
⁄2hp
No load speed 8,000 to 21,000min
-1
variable
Depth adjustment 1) Micro Winder
2) Free Plunge
Bit changes Through-base, single spanner action. Auto shaft lock
Guide Extended baseplate with adjustable fence
Protection Class
Net weight 3.9kg / 8.6lbs
Sound and vibration information:
Sound pressure (L
pa
) 85.5dB(A)
Sound power (L
wa
) 96.5dB(A)
Uncertainty (K) 3dB
Weighted vibration (A
h
) 5.958m/s
2
Uncertainty (K) 1.5m/s
2
As part of our ongoing product development, specifications of Triton products may alter without notice.
The sound intensity level for the operator may exceed 85dB(A) and sound protection measures are necessary.
