Thank you for purchasing this Triton tool. Please read these instructions: they contain information necessary for safe and
effective operation of this product. This product has a number of unique features and, even if you are familiar with similar
products, reading the instructions will help you get the full benefit of its unique design. Keep these instructions close to
hand and ensure all users of this tool have read and fully understand them.
SPECIFICATIONS
CONTENTS
Specifications 2
Symbols 2
Know your product 3
Safety instructions 4
Assembly 5
Setting up 5
Operation 6
Service and maintenance 9
Optional accessories 9
Warranty 9
Contents / Specifications / Symbols
Model No: SJA300
Clamping range: 0 - 1000mm / 39"
Clamping force: 1 TONNE (1000kg)/ 10,000Nm
Clamp travel per stroke: 24mm (1" approx)
Clamping Transmission type: 4 Pawl Teeth
Frame Tube: 25mm / 1"
Maximum load: 250kg / 550lb
Jaw Size: 205 x 80 x 7.5mm / 8 x 3
1
⁄7 x
1
⁄3"
Frame/Body Width: 105mm / 4
1
⁄8"
Folded size: 797 x 302 x 325mm / 3
11
⁄3 x 11
1
⁄2 x 12
1
⁄2"
Standing area: 1010 x 1060mm / 39
3
⁄4 x 41
3
⁄4"
Height: 875mm / 34
1
⁄2"
Weight: 19kg / 42lb
SYMBOLS
Always wear ear, eye and respiratory
protection.
Do not use before viewing and
understanding the full operating
instructions
Instruction warning.
Do not use this product as a step
or platform.
