Triton T80si User Manual

T80si pumped
2
I-001-A
IMPORTANT: When first installed the unit
will be empty. It is essential the unit should
contain water before the elements are
switched on. It is vital that the
commissioning procedure is followed.
Failure to carry out this operation will result
in damage to the unit and will invalidate the
guarantee.
The following points will help you understand
how the shower operates:
a. The electric heating elements operate at a
constant rate at your chosen power setting. It
is the flow rate of the water passing through
the heater unit which determines the shower
temperature at any given setting. (The slower
the flow the hotter the water becomes, and
the faster the flow the cooler the water).
b. During the winter the cold water supply
will be cooler than in the summer months.
Therefore, the temperature of the water
will vary from season to season on any one
setting of the temperature control, e.g. if
you have chosen 'medium' power for your
preferred shower temperature in the summer,
you may have to increase that to 'full' power
during the winter months.
c. If for any reason there is a sudden rise in
water temperature, the shower has thermal
cut-out devices built-in (see items 3 and 4
under ‘Fault Finding’).
d. If water ceases to flow switch off the shower at
the start/stop button and the isolating switch.
Contact Triton Customer Service for advice.
If ever the water becomes too hot and you
cannot obtain cooler water, first check that the
sprayplate in the showerhead is not blocked.
DO NOT place items such as soap or shampoo
bottles on top of the unit. Liquid could seep
through the joint between the cover and
backplate, and possibly damage the sealing
rubber.
This book contains all the necessary fitting and
operating instructions for your Triton pumped
electric shower. Please read them carefully and
keep for future reference.
The shower installation must be carried out by
a competent person and in the sequence of this
instruction book.
DO NOT attempt any electrical or plumbing
work necessary to install this product unless you
have good practical experience and adequate
understanding of the IEE regulations and water
regulations
Care taken during the installation will ensure a
long, trouble-free life from your shower.
Specifications
SPECIFICATIONS
Electrical
Nominal power Nominal power
rating at 240V rating at 230V
8.5kW – (40A MCB rating) 7.8kW – (40A MCB rating)
9.5kW – (40A MCB rating) 8.7kW – (40A MCB rating)
Water
Inlet connection – 15 mm diameter.
Outlet connection – ½” BSP male thread.
Entry Points
Water and cable – bottom, top or back.
Materials
Backplate, cover, controls, showerhead – ABS.
Sprayplate – Acetal.
Elements – Minerally insulated corrosion resistant
metal sheathing.
Dimensions
Height − 365 mm
Width − 245 mm
Depth − 104 mm
Standards and Approvals
Splashproof rating IPX4.
Complies with the requirements of current British
and European safety standards for household
and similar electrical appliances.
Complies with requirements of the British
Electrotechnical Approvals Board (BEAB).
Meets with Compliance with European
Community Directives (CE).
Introduction
INTRODUCTION
Advice to users
ADVICE TO USERS
Y-003-A
Replacement parts can be ordered from Customer
Service. See ‘spare parts’ for details and part numbers.

Triton T80si Specifications

General

Power Rating	8.5 kW
Installation	Wall Mounted
Water Entry Points	Bottom entry
Cable Entry Points	Bottom entry
Type	Instantaneous Electric Shower
