T90xr pumped electric shower

Fig.8

The PRD is situated behind the outlet pipe

(fig.6). To access the PRD, FIRST SWITCH OFF

THE ELECTRICITY SUPPLY, unscrew the hose

then remove the cover. Remove the two screws

holding the outlet pipe to the base of the can.

Carefully pull away from the can and then

unscrew the two screws holding the PRD to the

outlet pipe.

CAUTION: Do not attempt to replace the PRD

unless competent to do so.

Note: Before replacing the cover, it is strongly

advised to prime the unit (see ‘commissioning’).

Fig.7
