Triton VALDI User Manual

Vertical bar mixer shower
7
INSTALLATION
PREPARING THE MIXER VALVE
Check the contents to make sure all parts are
present.
Before starting the mixer installation, make
sure all the openings on the valve are carefully
covered to stop ingress of any debris, etc. while
routing the supply pipework.
The shower valve is suitable for exposed
installation onto solid wall, a stud partition wall,
dry lined wall or fixing to a laminate cubicle or
panel.
SITING OF THE SHOWER AND
ACCESSORIES
Refer to (fig.7) for correct siting of the shower.
The mixer valve should be positioned, as
detailed, with all controls within comfortable
reach of the user.
All dimensions listed in this fitting book regarding the product and installation are approximate.
Height of
showerhead
and shower
to suit user’s
requirement.
Kit can be
positioned
either side
of the mixer
shower
*Fig.7
*(diagrammatic view – not to scale)
