Triumph Bonneville Speedmaster User Manual

General Information
29
Traction Control (TC) Indicator Light
The Traction Control (TC)
indicator light is used to
indicate that the traction
control system is active and is
working to limit rear wheel slip during
periods of hard acceleration or under
wet or slippery road conditions.
Warning
If the traction control is not
functioning, care must be taken when
accelerating and cornering on wet/
slippery road surfaces to avoid rear
wheel spin.
Do not continue to ride for longer
than is necessary with the engine
management system Malfunction
Indicator Light (MIL) and traction
control warning lights illuminated.
Contact an authorised Triumph dealer
as soon as possible to have the fault
checked.
Hard acceleration and cornering in this
situation may cause the rear wheel
to spin resulting in loss of motorcycle
control and an accident.
If traction control is switched on:
• Under normal riding conditions the
TC indicator light will remain off.
• The TC indicator light will flash
rapidly when the traction control
system is working to limit rear
wheel slip during periods of hard
acceleration or under wet or
slippery road conditions.
If traction control is switched off:
• The TC indicator light will not
illuminate. Instead the TC disabled
warning light will be illuminated.
Note
Traction control will not function if there
is a malfunction with the ABS system.
The warning lights for the ABS, traction
control and the MIL will be illuminated.
Traction Control (TC) Disabled
Warning Light
The TC disabled warning light
should not illuminate unless
traction control is switched
off or there is a malfunction.
If the warning light becomes illuminated
at any other time while riding, it
indicates that the traction control
system has a malfunction that requires
investigation.
Low Fuel Indicator Light
The low fuel indicator light will
illuminate when there is
2.6 litres of fuel remaining in
the tank.
Neutral
The neutral warning light
indicates when the
transmission is in neutral (no
gear selected). The warning
light will illuminate when the
transmission is in neutral with the
ignition switch in the ON position.

Triumph Bonneville Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper, ABS
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Torque	106 Nm @ 4000 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Final Drive	Chain
Frame	Tubular steel
Front Brakes	Twin 310mm discs, Brembo 2-piston calipers, ABS
Front Wheel	16 x 2.5 in
Rear Wheel	16 x 3.5 in
Seat Height	705 mm
Fuel Tank Capacity	12 litres
Rear Suspension	Mono-shock RSU with linkage, 73mm rear wheel travel
Dry Weight	245kg
