Triumph Bonneville Speedmaster User Manual

How to Ride the Motorcycle
61
Stopping the Engine
Caution
The engine should normally be
stopped by turning the ignition switch
to the OFF position.
The engine stop switch is for
emergency use only.
Do not leave the ignition switched on
with the engine stopped. Electrical
damage may result.
To stop the engine:
• Close the throttle completely.
• Select neutral.
• Turn the ignition switch off.
• Select first gear.
• Position the motorcycle on a firm,
level surface with the side stand
(see page 69).
• Lock the steering (see page 43).
Starting the Engine
Warning
Never start the engine or run the
engine in a confined area.
Exhaust fumes are poisonous and can
cause loss of consciousness and death
within a short period of time.
Always operate the motorcycle in the
open air or in an area with adequate
ventilation.
Caution
Do not operate the starter
continuously for more than five
seconds as the starter motor will
overheat and the battery will become
discharged.
Wait 15 seconds between each
operation of the starter to allow for
cooling and recovery of battery power.
Do not let the engine idle for
long periods as this may lead to
overheating which will cause damage
to the engine.

Triumph Bonneville Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper, ABS
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Torque	106 Nm @ 4000 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Final Drive	Chain
Frame	Tubular steel
Front Brakes	Twin 310mm discs, Brembo 2-piston calipers, ABS
Front Wheel	16 x 2.5 in
Rear Wheel	16 x 3.5 in
Seat Height	705 mm
Fuel Tank Capacity	12 litres
Rear Suspension	Mono-shock RSU with linkage, 73mm rear wheel travel
Dry Weight	245kg
