General Information
32
Note
After refuelling, the average
consumption information will be updated
only while riding the motorcycle.
Depending on the riding style, updating
could take up to five minutes.
Fuel Gauge
2
1
1. Low fuel indicator light
2. Fuel gauge
The fuel gauge indicates the amount
of fuel in the tank. With the ignition
switched on, the number of bars shown
in the display indicates the level of fuel.
When the fuel tank is full all eight bars
are displayed and when empty, no bars
are displayed. Other gauge markings
indicate intermediate fuel levels
between full and empty.
The low fuel warning light will illuminate
when there is the following amount of
fuel left in the tank:
• 2.0 litres - Bonneville Bobber
• 3.0 litres - Bonneville Speedmaster.
Note
After refuelling, the fuel gauge and
range to empty information will
be updated only while riding the
motorcycle. Depending on the riding
style, updating could take up to five
minutes.
Range to Empty
21
1. Range to empty indicator
2. Estimated distance remaining
This is an indication of the predicted
distance that can be travelled on the
remaining fuel in the tank.
When less than a mile can be travelled
on the remaining fuel, then ‘---’ is
shown in the display.
Note
After refuelling, the fuel gauge and
range to empty information will
be updated only while riding the
motorcycle. Depending on the riding
style, updating could take up to five
minutes.

Triumph Bonneville Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper, ABS
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Torque	106 Nm @ 4000 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Final Drive	Chain
Frame	Tubular steel
Front Brakes	Twin 310mm discs, Brembo 2-piston calipers, ABS
Front Wheel	16 x 2.5 in
Rear Wheel	16 x 3.5 in
Seat Height	705 mm
Fuel Tank Capacity	12 litres
Rear Suspension	Mono-shock RSU with linkage, 73mm rear wheel travel
Dry Weight	245kg
