Triumph Speed Triple R User Manual

Maintenance and Adjustment
117
Compression Damping Adjustment -
Speed Triple R
1. Compression damping adjuster
The compression damping adjuster is
accessible from the left hand side of the
motorcycle. It is coloured gold and is
situated close to the rear suspension
reservoir.
To adjust the rebound damping setting,
rotate the adjuster clockwise to increase
rebound damping and anti-clockwise to
decrease.
Always count the number of clicks anti-
clockwise from the fully clockwise
position noting that the first stop (click
position) is counted as zero.
Note:
• The motorcycle is delivered from the
factory with the rebound adjuster
set at 19 clicks from the fully
clockwise position.
All Models
1
chcx_1
Warning
The rear suspension unit spring
pre-load is not rider adjustable.
Any attempt to adjust the spring
pre-load could result in a dangerous
riding condition leading to loss of
control and an accident.

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
