General Information
30
Clock Adjustment
To reset the clock, with the motorcycle
stationary and in neutral turn the
ignition to the ON position. Press and
release button 'A' until SEtUP is shown in
the display screen. Press button 'B’ until
t-SEt will be shown.
Press button 'B' again and either 24 Hr
or 12 Hr clock will be shown. Press
button 'A' to select the desired clock
display and then press button 'B'. The
hour display will start to flash and the
word Hour is shown in the display
screen.
To reset the hour display, make sure
that the hour display is still flashing and
the word Hour is shown. Press button 'A'
to change the setting. Each individual
button press will change the setting by
one digit. If the button is held, the
display will continuously scroll through
in single digit increments.
When the correct hour display is shown,
press button 'B'. The minutes display will
begin to flash and the word Min is
shown in the display screen. The
minutes display is adjusted in the same
way as for the hours.
Once both hours and minutes are
correctly set, press button 'B' to confirm
and t-SEt will be shown in the display
screen. Press and release button 'A' until
REtURn is shown then press button 'B'.
1. Hours read-out
2. Minutes read-out
3. Display screen (Hour selected for
adjustment)
4. Button B
5. Button A
Warning
Do not attempt to adjust the clock
with the motorcycle in motion as this
may lead to loss of motorcycle control
and an accident.
3
4
5
1
2
