Triumph Speed Triple R User Manual

Maintenance and Adjustment
99
If there is a malfunction with the throttle
control the Malfunction Indicator Light
(MIL) becomes illuminated and one of the
following engine conditions may occur:
• MIL illuminated, restricted engine
RPM and throttle movement
• MIL illuminated, limp-home mode
with the engine at a fast idle
condition only
• MIL illuminated, engine will not start.
For all of the conditions mentioned
contact an authorised Triumph dealer as
soon as possible to have the fault
checked and rectified.
Clutch
1. Clutch lever
2. Adjuster
3. Correct setting 2 - 3 mm
The motorcycle is equipped with a
cable-operated clutch.
If the clutch lever has excessive free
play, the clutch may not disengage fully.
This will cause difficulty in changing
gear and selecting neutral. This may
cause the engine to stall and make the
motorcycle difficult to control.
Conversely, if the clutch lever has
insufficient free play the clutch may not
engage fully, causing the clutch to slip,
which will reduce performance and
cause premature clutch wear.
Clutch lever free play must be checked in
accordance with scheduled maintenance
requirements.
1
2 - 3 mm
2
cggr
3

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
