General Information
51
System Display
1. TPMS symbol
2. Front tyre, identified
3. Rear tyre, identified
4. Tyre pressure display
5. Button A
6. Button B
To access the tyre pressure display, turn
the ignition to the ON position.
Press and release button 'A' until PSI or
bAR is shown in the display screen.
Press and release button 'B' to select
the front or rear tyre pressure.
When the tyre pressure monitoring
system has been selected, —— PSI or
bAR will be shown in the display screen
until the motorcycle is travelling at a
speed greater than 12 mph (20 km) and
the tyre pressure signal is received.
To exit the tyre pressure display, press
and release button 'A' to the desired
display.
Sensor Batteries
When the battery voltage in a pressure
sensor is low, LO bAt will be displayed
and the TPMS symbol will indicate which
wheel sensor has the low battery
voltage. If the batteries are completely
flat, only dashes will be shown in the
display screen, the red TPMS warning
light will be on and the TPMS symbol will
flash continuously. Contact your
authorised Triumph dealer to have the
sensor replaced and the new serial
number recorded in the spaces provided
on page 50.
1. TPMS symbol
2. Front tyre, identified
3. Rear tyre, identified
4. TPMS warning light
5. Tyre pressure display
With the ignition switch turned to the
ON position, if the TPMS symbol flashes
continuously and the TPMS warning
light remains on there is a fault with the
TPMS system. Contact your authorised
Triumph dealer to have the fault
rectified.
