Triumph Speed Triple R User Manual

Maintenance and Adjustment
91
Oil Level Inspection
1. Filler
2. Filler plug/dipstick
3. Upper marking
4. Lower marking
Note:
• An accurate indication of the level of
oil in the engine is only shown when
the engine oil is at normal operating
temperature, the motorcycle is
upright (not on the side stand) and
the filler plug/dipstick has been fully
screwed home.
Start the engine and run at idle for
approximately five minutes.
Stop the engine and wait for three
minutes to allow the oil to settle.
With the motorcycle upright, remove the
filler plug/dipstick, wipe the blade clean
and screw it fully home.
Remove the filler plug/dipstick.
The oil level is indicated by lines on the
filler plug/dipstick. When full, the
indicated oil level must be level with the
upper marking on the dipstick.
If the oil level is below the lower marking,
add oil a little at a time until the correct
level is reached. Once the correct level is
reached, re-fit the filler plug/dipstick.
ccpu_1
3
2
1
4
Warning
Never start the engine or run the
engine in a confined area. Exhaust
fumes are poisonous and can cause
loss of consciousness and death
within a short period of time.
Always operate your motorcycle in the
open-air or in an area with adequate
ventilation.
Caution
Running the engine with insufficient
oil will cause engine damage. If the low
oil pressure indicator remains on, stop
the engine immediately and
investigate the cause.

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
