Parts Identification
16
Parts Identification (continued)
1. Clutch lever
2. High beam button
3. SCROLL button
4. Daytime Running Lights (DRL) switch
(if fitted)
5. Speedometer
6. Trip computer display
7. Tachometer
8. Warning lights
9. Front brake fluid reservoir
10. Engine start/stop switch
11. Front brake lever
12. Horn button
13. Direction indicator switch
14. MODE button
15. Ignition switch
16. Hazard button
432 5 6 7 8 9 10
13 15
12
1
14
11
16
