Triumph Speed Triple R User Manual

General Information
41
Note:
• It is not possible to select the RIDER
mode whilst the motorcycle is in
motion if ABS and/or TTC are set to
Off when setting the RIDER mode
options (see page 43).
Press and release the MODE button on
the left handlebar switch housing until
the desired riding mode is flashing in the
display.
1. Selected riding mode (flashing)
2. Current (active) riding mode
The selected riding mode is
automatically activated if within
30 seconds of pressing the MODE button
the following has been carried out
simultaneously:
• Close the throttle
• Pull the clutch in
• Ensure that the brakes are not
engaged (allow the motorcycle to
coast).
Once the MAP, ABS and TTC settings
have changed, the selected riding mode
will be displayed and the previous mode
will no longer be shown.
1. Selected riding mode
Resume riding as normal.
Note:
• If any one of the systems (MAP, ABS
or TTC) fails to change to the
settings specified by the selected
riding mode, both the previous and
the selected riding mode icons will
flash.
1. Incomplete mode change (flashing)
2
1
1
1

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
