GENERAL INFORMATION
103
Fill the fuel tank slowly to help prevent
spillage. Do not fill the tank to a level
above the bottom of the filler neck.
This will make sure there is enough air
space to allow for fuel expansion if the
fuel inside the tank expands through
absorption of heat from the engine or
from direct sunlight.
2
1
1. Fuel filler neck
2. Maximum fuel level
After refueling always check that the
fuel filler cap is correctly closed.
Cruise Control (if equipped)
Street Triple RS and
Street Triple Moto2™ Edition
Warning
Cruise control must only be used
where you can ride safely at a steady
speed.
Cruise control should not be used
when riding in heavy traffic, on roads
with sharp/blind bends or when they
are slippery.
Using cruise control in heavy traffic,
on roads with sharp/blind bends or
when they are slippery, may result
in loss of motorcycle control and an
accident.
Warning
This Triumph motorcycle should be
operated within the legal speed limits
for the particular road traveled.
Operating a motorcycle at high speeds
can be potentially dangerous since the
time available to react to given traffic
situations is greatly reduced as road
speed increases.
Always reduce speed in potentially
hazardous driving conditions such as
bad weather or heavy traffic.

Triumph Street Triple Moto2 Edition Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	765 cc
Max Torque	80 Nm @ 9, 500 rpm
Transmission	6-speed
Dry Weight	166 kg
Front Brakes	Twin 310 mm floating discs, Brembo Stylema 4-piston radial monobloc calipers
Rear Brakes	Single 220 mm disc, Brembo single piston caliper
Fuel Tank Capacity	15 litres
Frame	Aluminium beam twin spar
Wheels	17 x 3.5 in (front), 17 x 5.5 in (rear)
Front Suspension	Öhlins 43 mm NIX30 upside down forks, adjustable compression and rebound damping
