Triumph Street Triple Moto2 Edition User Manual

GENERAL INFORMATION
58
Speedometer
The speedometer indicates the road
speed of the motorcycle.
1
MPH
1. Speedometer
Odometer
The odometer shows the total distance
that the motorcycle has traveled.
The odometer is shown in the Service
display.
mi
12/2024
2611
0000689
mi
OR
1
SERVICE INTERVAL
1. Odometer
Tachometer
Caution
Never allow engine speed to enter the
red zone as severe engine damage
may result.
The tachometer shows the engine
speed in revolutions per minute - rpm
(r/min). At the end of the tachometer
range there is the red zone. Engine
speeds in the red zone are above
maximum recommended engine speed
and are also above the range for best
performance.
1
2
MPH
1. Engine speed (rpm)
2. Red zone

Triumph Street Triple Moto2 Edition Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	765 cc
Max Torque	80 Nm @ 9, 500 rpm
Transmission	6-speed
Dry Weight	166 kg
Front Brakes	Twin 310 mm floating discs, Brembo Stylema 4-piston radial monobloc calipers
Rear Brakes	Single 220 mm disc, Brembo single piston caliper
Fuel Tank Capacity	15 litres
Frame	Aluminium beam twin spar
Wheels	17 x 3.5 in (front), 17 x 5.5 in (rear)
Front Suspension	Öhlins 43 mm NIX30 upside down forks, adjustable compression and rebound damping
