GENERAL INFORMATION
89
Fuel Gage
The fuel gage indicates the amount of
fuel in the tank.
3
52
21.5 10:55
AM
x1000rpm
SET 100
9
ABS
+
MPH
0
2
4
6
8
10
12
14
0
2
4
6
8
10
12
14
1
CURRENT RANGEAVERAGE
FUEL STATUS
HOLD TO RESET
F E C H
°C
49.8
42.3
204.8
mpg
mpg mi
1. Fuel gage
The fuel gage colors described below
may vary by different styles.
With the ignition switched on, a black
line indicates the fuel remaining in the
fuel tank.
When the fuel tank is full, a black line
is shown and when empty, a gray line
is shown. Other gage markings indicate
intermediate fuel levels between full and
empty.
The low fuel warning light will illuminate
when approximately 3.5 litres of fuel is
remaining in the tank and you should
refuel at the earliest opportunity. The
range to empty and instantaneous fuel
consumption will be also shown in the
Information tray. Press the joystick
center to acknowledge and hide the low
fuel warning.
After refueling, the fuel gage and range
to empty information will be updated
only while riding the motorcycle.
Depending on the riding style, updating
could take up to five minutes.
Coolant Temperature Gage
The coolant temperature gage indicates
the temperature of the engine coolant.
3
52
21.5 10:55
AM
x1000rpm
SET 70
9
ABS
+
MPH
1
0
2
4
6
8
10
12
14
0
2
4
6
8
10
12
14
1
TRIP 1
HOLD TO RESET
DURATIONAVG. SPEEDDISTANCE
°C
F
E
C
H
1234
mi
34.5 23:45
mph
hh:mm
1. Coolant temperature gage
When the engine is started from cold
the display will show gray bars. As the
temperature increases more bars in
the display will be shown illuminated.
When the engine is started from hot the
display will show the relevant number of
illuminated bars, dependent on engine
temperature.
The normal temperature range is
between the C (Cold) and H (Hot) on the
display.
With the engine running, if the
engine coolant temperature becomes
dangerously high, the high coolant
temperature warning light on the
display will be illuminated and the gage
will display in the information tray.
