Triumph Street Triple Moto2 Edition User Manual

MAINTENANCE
169
Front Suspension Rebound and
Compression Damping Adjustment
Street Triple R
cjyc
1
2
1. Compression damping adjuster (COM)
2. Rebound damping adjuster (TEN)
To change the rebound damping setting:
▼ Rotate the TEN slotted adjuster
clockwise to increase, or
counterclockwise to decrease.
▼ Always count the number of turns
from the fully clockwise position.
To change the compression damping
setting:
▼ Rotate the COM slotted adjuster
clockwise to increase, or
counterclockwise to decrease.
▼ Always count the number of turns
from the fully clockwise position.
Street Triple RS
The rebound and compression damping
adjusters are located at the top of each
fork.
cjyf
1
2
1. Compression damping adjusters
2. Rebound damping adjusters
Street Triple Moto2™ Edition
The compression damping adjuster is
located at the top of the left hand fork.
1
1. Compression damping adjuster
To change the compression damping
force:
▼ Using a 0.12 in (3 mm) Allen key,
rotate the adjuster clockwise to
increase, or counterclockwise to
decrease.

Triumph Street Triple Moto2 Edition Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Engine Capacity	765 cc
Max Torque	80 Nm @ 9, 500 rpm
Transmission	6-speed
Dry Weight	166 kg
Front Brakes	Twin 310 mm floating discs, Brembo Stylema 4-piston radial monobloc calipers
Rear Brakes	Single 220 mm disc, Brembo single piston caliper
Fuel Tank Capacity	15 litres
Frame	Aluminium beam twin spar
Wheels	17 x 3.5 in (front), 17 x 5.5 in (rear)
Front Suspension	Öhlins 43 mm NIX30 upside down forks, adjustable compression and rebound damping
